CONNECTORS
Q-G ? Audio Connector Series
B, C, D, E Panel Style Series
Switchcraft also offers a wide range
47
E3FSC
D*MS
D*F
D*MBAU
of panel mount connectors.
The B Series features a round
housing with a threaded collar for
mounting. The female version requires
a spanner wrench to tighten the
connector to the chassis. Both
male and female are available with
black finish.
The C Series is another round
housing panel mount, which has
0.140" mounting holes requiring
#5-40 screws to mount.
B*F
C*F
C*MB
The D Series, our most popular
version, is a rectangle housing
panel mount. The standard Rawall
finish resists scratching, while the
Ordering Information
B*MB
Pins/
optional satin finish offers a smooth
finish for mounting on a brushed
finished chassis.
The E Series offers a panel
mount with quick release inserts. A
small screwdriver is used to remove
the inserts, allowing for easy gender
changes. The male and female E
Series fit into the same panel cut-outs.
The E Series is also available
with PC terminals. Contact the
factory for details.
Part Number
B*F, B*M
Style
Panel
Finish
Nickel
Contacts
Silver
Notes
Threaded Collar
B*FB, B*MB Panel
Black
Silver
Threaded Collar
C*F, C*M
Panel
Nickel
Silver
Uses #5-40 mounting screws
C*FB, C*MB Panel
Black
Silver
Uses #5-40 mounting screws
D*F, D*M
Panel
Nickel
Silver
Uses #5-40 mounting screws
D*FB, D*MB Panel
D*FBAU, D*MBAU Panel
D*FS, D*MS Panel
E3FSC, E3MSC Panel
E3FSCB, E3MSCB Panel
Black
Black
Nickel
Nickel
Black
Silver
Gold
Silver
Silver
Silver
Rectangle housing
Rectangle housing
Rectangle housing, smooth finish
Male/Female same panel cut-out
Male/Female same panel cut-out
E3FSCBAU,
E3MSCBAU Panel
Black
Gold
Male/Female same panel cut-out
* Available 3 - 7 pins or contacts
See Page 57 for Mechanical Drawings
5555 North Elston Avenue / Chicago, IL 60630
Phone: 773-792-2700 / Fax: 773-792-2129
